Content Policy Platform - Complete Documentation

📋 Project Overview

🌐

API Gateway & User Portal

Full-stack application built with Node.js backend and Next.js frontend providing user authentication, API key management, and usage analytics.

🔐 JWT Authentication System
🔑 API Key Management (Max 3/user)
📊 Usage Analytics & Quota Tracking
💻 React-based Web Dashboard

🐍

Python RAG API

FastAPI-based content moderation service with AI-powered analysis using Google Gemini and ChromaDB vector database.

🛡️ AI-Powered Content Moderation
📚 Vector Database Integration
🎯 Custom Rule Management
🔒 Multi-User Environment Support

🏗️ System Architecture

High-Level Architecture

Frontend Layer

Next.js 15 with React 19, TypeScript, and Tailwind CSS for modern, responsive UI

API Gateway Layer

Node.js/Express backend with SQLite database and JWT authentication

AI Moderation Layer

FastAPI with ChromaDB vector database and Google Gemini AI integration

🎥 Video Demo

Platform Walkthrough

Watch this comprehensive demo to see the Content Policy Platform in action, including user authentication, API key management, content moderation setup, and real-time testing of the AI-powered moderation system.

User Portal Demo API Key Creation Content Moderation Real-time Testing

📁 Project Structure

Complete Project Layout

The project consists of two main applications with comprehensive documentation and testing scripts.





Project Directory Tree

                                📂 Moderato/
├── 📁 apigateway-v1/                    // API Gateway & User Portal
│   ├── 📁 .github/workflows/
│   │   └── 📄 ci.yml                   // GitHub Actions CI/CD
│   ├── 📁 nodejs-backend/               // Node.js API Service
│   │   ├── 📁 database/
│   │   │   ├── 📄 schema.sql
│   │   │   └── 📄 sqlite-schema.sql
│   │   ├── 📁 src/
│   │   │   ├── 📄 server.js            // Express server & routes
│   │   │   ├── 📄 auth.js              // JWT authentication
│   │   │   ├── 📄 database.js          // SQLite operations
│   │   │   ├── 📄 apikeys.js           // API key management
│   │   │   ├── 📄 quota.js             // Usage tracking
│   │   │   ├── 📄 models.js            // Data models
│   │   │   ├── 📄 utils.js             // Utilities
│   │   │   └── 📄 endpoints.js         // Public API endpoints
│   │   ├── 📄 package.json             // Project configuration
│   │   └── 📄 README.md
│   ├── 📁 userportal/                   // Next.js Frontend
│   │   ├── 📁 app/                     // Next.js app router
│   │   │   ├── 📁 api-testing/
│   │   │   ├── 📁 apikeys/
│   │   │   ├── 📁 auth/
│   │   │   ├── 📁 docs/
│   │   │   ├── 📁 settings/
│   │   │   ├── 📄 layout.tsx
│   │   │   └── 📄 page.tsx
│   │   ├── 📁 components/               // React components
│   │   │   ├── 📄 ApiKeyManagement.tsx
│   │   │   ├── 📄 DashboardHome.tsx
│   │   │   ├── 📄 LoginForm.tsx
│   │   │   └── 📄 ... (15+ components)
│   │   ├── 📁 hooks/                   // Custom React hooks
│   │   ├── 📁 lib/                     // Utility libraries
│   │   ├── 📄 package.json
│   │   └── 📄 tsconfig.json
│   ├── 📄 API_DOCUMENTATION.md          // Complete API docs
│   ├── 📄 README.md                    // Main documentation
│   └── 📄 *.bat, *.sh, *.ps1           // Testing & setup scripts
├── 📁 python-rag-api/                  // AI Content Moderation API
│   ├── 📁 app/
│   │   ├── 📁 core/
│   │   │   └── 📄 config.py            // Environment configuration
│   │   ├── 📁 endpoints/
│   │   │   └── 📄 moderation.py        // API endpoints
│   │   ├── 📄 main.py                  // FastAPI application
│   │   ├── 📄 services.py              // Business logic
│   │   └── 📄 schemas.py               // Pydantic models
│   ├── 📁 chroma_db/                   // Vector database storage
│   ├── 📄 requirements.txt             // Python dependencies
│   ├── 📄 test_client.html             // HTML test interface
│   └── 📄 README.md
├── 📁 docs/                            // Documentation Website
│   ├── 📄 index.html                   // Main documentation page
│   ├── 📄 styles.css                   // Dark theme styling
│   └── 📄 script.js                    // Interactive functionality
└── 📄 COMPLETE_PROJECT_DOCUMENTATION.md // Comprehensive guide


🛠️ Technology Stack

Backend

Node.js Express.js FastAPI SQLite ChromaDB Google Gemini AI

Frontend

Next.js 15 React 19 TypeScript Tailwind CSS 4 Heroicons

Security

JWT Tokens SHA256 Hashing API Key Auth CORS Environment Variables

🌐 API Gateway & User Portal

🔐 Authentication System

User Registration/Login: Email validation and secure password handling
JWT Token Management: 1-hour expiry with secure token tracking
Password Security: SHA256 hashing with salt protection
Token Revocation: Immediate invalidation on logout

🔑 API Key Management

Secure Generation: 32-character hash with 'ak_' prefix
User Limits: Maximum 3 API keys per user account
Status Control: Active/inactive/revoked states
Usage Tracking: Lifetime and monthly statistics

📊 Quota System

Monthly Limits: 100 requests per API key per month
Auto Reset: Automatic quota reset on first day of month
Real-time Monitoring: Live usage updates and warnings
Enforcement: HTTP 429 when quota exceeded

🐍 Python RAG API

🤖 AI-Powered Moderation

Google Gemini Integration: Advanced language model for content analysis
Semantic Rule Matching: Vector similarity search for relevant rules
Multi-Rule Evaluation: Comprehensive analysis against multiple policies
Confidence Scoring: Detailed reasoning for moderation decisions

📚 Vector Database

ChromaDB Integration: Efficient semantic search capabilities
Rule Storage: Persistent storage with metadata and context
Top-K Retrieval: Finds 5 most relevant rules per query
Auto Initialization: Automatic database setup and management

🎯 Custom Rules

User-Specific Rules: Organized by API key and user ID
CRUD Operations: Complete rule lifecycle management
Flexible Format: Support for complex, multi-paragraph policies
Real-time Updates: No service restart required for rule changes

🚀 Quick Start Guide

1

Prerequisites

# Required Software
- Node.js (18.0+)
- npm or yarn
- Python (3.11+)

2

Start API Gateway

# Backend (Node.js)
cd apigateway-v1/nodejs-backend
npm install
npm start

# Frontend (Next.js)
cd apigateway-v1/userportal
npm install
npm run dev

3

Start Python RAG API

# Setup Environment
cd python-rag-api
python -m venv .venv
.venv\Scripts\activate  # Windows

# Install & Configure
pip install -r requirements.txt
# Create .env with GEMINI_API_KEY

# Start Service
uvicorn app.main:app --reload

4

Access Applications

🌐 User Portal localhost:3000 ⚡ API Gateway localhost:8080 🐍 Python API 127.0.0.1:8000

📚 API Documentation

API Gateway Endpoints (Port 8080)

Authentication

POST /api/auth/register User registration

POST /api/auth/login User login

GET /api/auth/profile User profile (protected)

API Key Management

POST /api/apikeys Create API key

GET /api/apikeys List user's keys

PUT /api/apikeys/{id}/status Enable/disable key

Python RAG API Endpoints (Port 8000)

Rule Management

POST /add-rule/ Add moderation rule

GET /rules/{user_id}/{api_key}/ Get user's rules

DELETE /delete-rule/{rule_id}/ Delete specific rule

Content Moderation

POST /moderate/ Moderate text content

🎯 Use Cases

📱

Social Media Platform

AI-powered content moderation for user-generated content with custom community guidelines and real-time analysis.

Real-time Moderation Custom Rules Multi-language

🏢

Enterprise SaaS

Multi-tenant content policy management with client isolation and environment-specific rule sets.

Client Isolation Environment Separation Compliance

💻

Developer Platform

API key management with quota tracking and usage analytics for development teams.

Quota Management Team Access Analytics
